JLG 55' 10,000 lb Telehandler
1055
Contact Us
Currently Available

Key Specs

  • Maximum Lift Capacity: 10000 lb / 4535.92 kg
  • Outriggers Up Max Lift Height: 55 ft / 16.76 m
  • Maximum Reach: 42 ft / 12.8 m
  • Maximum Lift Height: 55 ft / 16.76 m

Key Features

  • Enhanced operator comfort—spacious cab, intuitive single joystick and integrated arm rest
  • Maximum serviceability—external telescope cylinder and easily accessible filters and parts
  • Greater operator confidence—Stabil-Trak rear axle stabilization, new reverse sensing system, reversing camera and better visibility from the cab
  • Increased versatility—expanded attachment offering includes pipe grapple, trash hopper and material handling arm

Equipment specifications

Drawbar Pull
25400 lb / 11521.25 kg
Frame Leveling
10 Degrees
Load Center
2 ft / 0.61 m
Maximum Lift Capacity
10000 lb / 4535.92 kg
Outriggers Up Max Lift Height
55 ft / 16.76 m
Outriggers Up Max Forward Reach
42 ft / 12.8 m
Lift Capacity at Full Height
5000 lb / 2267.96 kg
Lift Capacity at Max Reach
3000 lb / 1360.78 kg
Maximum Reach
42 ft / 12.8 m
Maximum Lift Height
55 ft / 16.76 m
Outriggers or Stabilizers
Yes
Outside Turning Radius
14 ft / 4.27 m
Speed - Maximum Lift
14 sec.
Speed - Maximum Lower
11 sec.
Speed - Maximum Telescope In
15 sec.
15 sec. Speed - Maximum Telescope Out
16 sec.
Speed - Maximum Travel
20 mph / 32.19 km/h
Dimensional Data
Ground Clearance
1 ft 6 in. / 0.46 m
Machine Height
8 ft 4 in. / 2.54 m
Machine Length
20 ft 1 in. / 6.12 m
Machine Width
8 ft 5 in. / 2.56 m
Tire Size
400/75-28
Wheelbase
11 ft 6 in. / 3.49 m
Power Source
Capacity - Fuel Tank
38 gal. / 144.98 L
Engine Horsepower
130 hp / 96.98 kW
Engine Manufacturer
Cummins
Engine Model
QSF3.8L Tier 4 F
Maximum Engine RPM
1500 rpm
General
Axle-Front
High Bias, Limited Slip
Axle-Rear
Planetary
Function Pump Type
Load Sensing Piston
Operating Vehicle Weight
31559 lb / 14314.92 kg
Service Brake Type
Wet Multi-Disc
Transmission - Nr Forward Gears Standard
4
Transmission - Nr Reverse Gears
3
Transmission Type
Powershift
