JLG 42' 9,000 Telehandler
943
Contact Us
Currently Available
Key Specs
- Maximum Lift Capacity: 9000 lb / 4082.33 kg
- Maximum Lift Height: 43 ft / 13.11 m
- Maximum Reach: 30 ft 5 in. / 9.27 m
Key Features
- Enhanced operator comfort—spacious cab, intuitive single joystick and integrated arm rest
- Maximum serviceability—external telescope cylinder and easily accessible filters and parts
- Greater operator confidence—Stabil-Trak rear axle stabilization, new reverse sensing system, reversing camera and better visibility from the cab
- Increased versatility—expanded attachment offering includes pipe grapple, trash hopper and material handling arm
Equipment specifications
Drawbar Pull
22751 lb / 10319.68 kg
Frame Leveling
10 Degrees
Lift Capacity at Full Height
7000 lb / 3175.15 kg
Lift Capacity at Max Reach (Stabs Up)
1200 lb / 544.31 kg
Load Center
2 ft / 0.61 m
Maximum Lift Capacity
9000 lb / 4082.33 kg
Maximum Lift Height
43 ft / 13.11 m
Maximum Reach
30 ft 5 in. / 9.27 m
Outriggers or Stabilizers
No
Outside Turning Radius
12 ft / 3.66 m
Speed - Maximum Lift
13 sec.
Speed - Maximum Lower
9 sec.
Speed - Maximum Telescope In
13 sec.
Speed - Maximum Telescope Out
15 sec.
Speed - Maximum Travel
19 mph / 30.58 km/h
Ground Clearance
1 ft 5 in. / 0.43 m
Machine Height
8 ft 2 in. / 2.49 m
Machine Length
19 ft 9 in. / 6.02 m
Machine Width
8 ft 1 in. / 2.46 m
Tire Size
370/75-28
Wheelbase
11 ft 3 in. / 3.43 m
Dimensional Data
Capacity - Fuel Tank
38 gal. / 144.98 L
Engine Horsepower
110 hp / 82.06 kW
Engine Manufacturer
Cummins
Engine Model
QSF3.8L Tier 4 Final
Maximum Engine RPM
1500 rpm
General
Axle-Front
High Bias, Limited Slip
Axle-Rear
Planetary
Function Pump Type
Load Sensing Piston
Operating Vehicle Weight
24912 lb / 11299.89 kg
Service Brake Type
Wet Multi-Disc
Transmission - Nr Forward Gears Standard
4
Transmission - Nr Reverse Gears
3
Transmission Type
Powershift
