JLG 12,000 lb Telehandler
Currently Available
Key Specs
- Maximum Lift Capacity: 12000 lb / 5443.11 kg
- Outriggers Up Max Lift Height: 55 ft / 16.76 m
- Maximum Reach: 42 ft / 12.8 m
- Maximum Lift Height: 55 ft / 16.76 m
Key Features
- Spacious cab, intuitive single joystick and integrated arm rest for enhanced operator comfort
- External telescope cylinder and easily accessible filters and parts for maximum serviceability
- Greater visibility from the cab, new reverse sensing system and reversing camera options for enhanced operator confidence
Performance |
|
| Drawbar Pull | 25400 lb / 11521.25 kg |
| Frame Leveling | 10 Degrees |
| Load Center | 2 ft / 0.61 m |
| Maximum Lift Capacity | 12000 lb / 5443.11 kg |
| Outriggers Up Max Lift Height | 55 ft / 16.76 m |
| Outriggers Up Max Forward Reach | 42 ft / 12.8 m |
| Lift Capacity at Full Height | 5000 lb / 2267.96 kg |
| Lift Capacity at Max Reach | 3500 lb / 1587.57 kg |
| Maximum Reach | 42 ft / 12.8 m |
| Maximum Lift Height | 55 ft / 16.76 m |
| Outriggers or Stabilizers | Yes |
| Outside Turning Radius | 14 ft / 4.27 m |
| Speed - Maximum Lift | 16 sec. |
| Speed - Maximum Lower | 13 sec. |
| Speed - Maximum Telescope In | 15 sec. |
| Speed - Maximum Telescope Out | 18 sec. |
| Speed - Maximum Travel | 20 mph / 32.19 km/h |
Equipment specifications
Drawbar Pull
25400 lb / 11521.25 kg
Frame Leveling
10 Degrees
Load Center
2 ft / 0.61 m
Maximum Lift Capacity
12000 lb / 5443.11 kg
Outriggers Up Max Lift Height
55 ft / 16.76 m
Outriggers Up Max Forward Reach
42 ft / 12.8 m
Lift Capacity at Full Height
5000 lb / 2267.96 kg
Lift Capacity at Max Reach
3500 lb / 1587.57 kg
Maximum Reach
42 ft / 12.8 m
Maximum Lift Height
55 ft / 16.76 m
Outriggers or Stabilizers
Yes
Outside Turning Radius
14 ft / 4.27 m
Speed - Maximum Lift
16 sec.
Speed - Maximum Lower
13 sec.
Speed - Maximum Telescope In
15 sec.
Speed - Maximum Telescope Out
18 sec.
Speed - Maximum Travel
20 mph / 32.19 km/h
Dimensional Data
Ground Clearance
1 ft 6 in. / 0.46 m
Machine Height
8 ft 4 in. / 2.54 m
Machine Length
20 ft 1 in. / 6.12 m
Machine Width
8 ft 5 in. / 2.56 m
Tire Size
400/75-28
Wheelbase
11 ft 6 in. / 3.49 m
Power Source
Capacity - Fuel Tank
38 gal. / 144.98 L
Engine Horsepower
130 hp / 96.98 kW
Engine Manufacturer
Cummins
Engine Model
QSF3.8L Tier 4 Final
Maximum Engine RPM
1500 rpm
General
Axle-Front
High Bias, Limited Slip
Axle-Rear
Planetary
Function Pump Type
Load Sensing Dual Gear
Operating Vehicle Weight
Load Sensing Dual Gear
Operating Vehicle Weight
33960 lb / 15404 kg
Transmission - Nr Forward Gears Standard
4
Transmission - Nr Reverse Gears
3
Transmission Type
Powershift
