170,OOO BTU Propane Heater
L.B. White Tradesman CP170
Contact Us
Currently Available
Engineered to deliver reliable, directional heat, L.B. White Tradesman® portable heaters feature a unique 3-trial ignition system, the industry's heaviest gauge combustion chamber and burner plate, and Self Diagnostic Service Saver models for convenient trouble-shooting. L.B. White has perfected every aspect of our portable construction heaters design to withstand harsh working environments. This has led to our reputation for reliability, durability and serviceability in the field. When the comfort and safety of your work crew is at stake… you want the leader in portable heating equipment for any commercial, industrial or construction job… L.B White.
Key features:
- Available in models ranging from 100,000 to 400,000 Btu/h
- Propane gas and natural gas (NG) models available
- Ultra models include Self Diagnostic Service Saver for convenient trouble-shooting
- Dependable electronic spark ignition
- Superior tri-shield finish provides extended protection against abrasion and corrosion.
- Thermostatic temperature control (170 and 400 models)
- Adjustable front leg provides easy direction of heat (170 model)
- Variable output saves fuel
- 100% test fired at our plant
- Direct-fired = 99.97% fuel efficiency
- CSA US and Canadian certified
Tradesman 170 Parts Diagram Exploded View
Call for pricing & availability!
Equipment specifications
Model
Tradesman 170
Maximum / Minimum Input (BTUH):
170,000/125,000
Heated Air Output (CFM)
625
Ignition Type
Spark-Auto
Electrical Supply (Volts / Hz/ Phase)
115 / 60 / 1
Amps (Starting / Cont. Oper)
3.7 / 2.1
L x W x H
24" x 9.5" x 16"
Weight
29.2lbs
High Temp Safety Switch
Yes
Air Flow Safety Switch
Yes
Gas
Inlet Gas Supply Pressure Acceptable at the Gas Connection of the Heater (in. W.C.):
Propane Gas (min/max): 11.1 | Natural Gas (min/max): 7 / 13.5
Fuel Consumption lbs. Per Hour:
Propane Gas (min/max): 5.8 / 7.9 | Natural Gas (min/max): 125 / 155
